C50 Metal Sheet Coater
Contact Us
Binjiang Avenue (Yanjiang Industrial Base), Jiujiang City, Jiangxi Province, China
+86 17707924676
jjyixin2020@gmail.com
C50 metal sheet coating machine is a high-precision, fully automatic coating machine with vertical and horizontal blanking functions.It is suitable for priming or glazing coating on tinplate, aluminum plate and other metal plates, and it is one of the necessary equipment for printing iron and can making enterprises.
C50 metal sheet coating machine is a high-precision, fully automatic coating machine with vertical and horizontal blanking functions.It is suitable for priming or glazing coating on tinplate, aluminum plate and other metal plates, and it is one of the necessary equipment for printing iron and can making enterprises.
coating speed | 1145X965mm |
Maximum sheet metal size | 1200X1000mm |
Minimum sheet metal size | 712X508mm |
Sheet metal thickness | 0.16-0.6mm |
Rubber Roller Diameter | Ф350-Ф360mm (when fully coated) |
Diameter of oil transfer roller | Ф220mm |
Oil roller diameter | Ф200mm |
main motor power | 7.5W |
Machine net weight | 7500kg |
Machine size (length X width X height) | 8985X2490X1950mm (with sample table) 6260X2490X1950mm without sample table) |
